WH948-MZ, Micro-Z Point-of-Entry Sediment Water Filter, 4-7 GPM

$745.00 - $1,039.00

Qty Price Ea.
2 $845.00
4 $795.00
8 + $745.00
Price Per Unit
WH948-MZ$745.00 - $1,039.00
$745.00 - $1,039.00
  • 4 – 7 Gallons Per Minute Flow Rate
  • Clears Up Cloudy Water
  • Fleck Backwashing Control Valve
  • Nominal 5 Micron Filtration
  • Removes Dirt, Rust & Sediment

Uses for Water Filtration

MicroZ high performance granular filter media that outperforms conventional multimedia due to its unique zeolite structure, 2.8x’s the load capacity of sand. Micro-Z media is capable of handling higher service flow rate and increased load capacity. 5 – 10 micron nominal rating.

MicroZ Automatic Backwashing Sediment Filters are designed to remove ferric iron (rust), silt, and turbidity. This system is sized for a small house or cabin with 2 or 3 bathrooms.


  • Fleck 5800SXT Digital Backwashing Control Valve
  • Structural Polyglass Tank
  • Micro-Z Uses 50% Less Water for Backwashing Compared to Sand Filters
  • Nominal 5 – 10 Micron Filtration
  • Media Never Needs to be Replaced!
  • No Chemicals or Salts Used
  • 1" MPT Noryl Yoke Standard Connection & Bypass Valve

For Superior Filtration, Reduce Flow Rates by 1/3 of the Standard Flow Rate Specification.

Cloudy Water Due to Debris

Cloudy water due to dirt and debris in the water.

Well Water Assembly Diagram

Well water system assembly instructions included with this system.

Additional information

Amount of Media

1.0 Cu. Ft.

Gallons Per Minute

4-7 GPM

Material Composition


Media Type

Media Bed Life


Tank Size

Country of Origin

Controller Type: Fleck 5600SXT Amount of Media: 1 Cubic Foot
Media Tank Type: Structural Polyglass Service / Peak Flow: 4 / 7 GPM
Media Tank Size: 54" (H) × 10" (D) Operating Pressure: 20 - 125 PSI
Overall System Height: 58.25" Operating Temperature: 36 - 120° F
Media Replacement: Never Shipping Weight: 91 LBS

WH948-MZ Well Water System Installation
